Pentair Sta-Rite D Series High Head Centrifugal Pumps

Available in high head or medium head series (separate listing for Medium Head). Feature leak-proof mechanical seals, easy service design, heavy-duty motors, rugged construction.

• Body and Base: Close-grained cast iron
• Impeller: Noryl® on 1 through 2-1/2 HP, bronze on 3 and 5 HP
• Diffuser: Cast iron
• Shaft: 1 through 2-1/2 HP: 416 stainless steel; 3 and 5 HP: Carbon steel inside removable shaft sleeve of stainless steel.
• Max Inlet Pressure: 20 PSI
• Max Discharge Pressure: 100 PSI
• Max Liquid Temperature: 60°C/140°F
• Max Ambient Air Temperature: 40°C/104°F
